| Brand Name : | Coolmay |
| Model Number : | QM3G-43FH |
| Certification : | CE |
| Price : | usd90-usd165 per piece |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 5000pcs/month |
| Delivery Time : | 5-7 working days |
Original Integrated HMI Programmable Logic Controller 4.3 Inch
Coolmay Original Integrated Hmi Plc All In One 4.3 Inch For Industrial
All-in-One PLC integrates the controller with the HMI panel, creating a compact, easy-to-use automation solution. Users no longer need to establish PLC to panel communications.
All-in-one device application can saves time, reduces wiring, and cuts the cost of purchasing multiple devices.
Model : QM3G-43FH-24M
Resolution : 480 x 272
Digital Input : 12
Digital Output: 12 (Relay or Transistor as customized requirements)
Analog Input : 4 (Optional with different signal type)
Analog Output : 2 (Optional with different signal type)
HMI / PLC downloading Port : Type C .
| Model | QM3G-43FH-24M | |
| Display | Dimension | 134*102*34mm |
| Cutout size | 120*94mm | |
| Power Consumption | 4-6W | |
| Feature | 60K-color resistive touch screen, supports portrait display | |
| I/O | DI/DO | Max 12DI/12DO |
| DI/DO level | Input: Passive NPN, public terminal isolatedTransistor output: Low level NPN, COM connect to negative; Relay output: Normally open dry contact | |
| DO type | Relay MR or MOS (Relay output: max load 5A/ MOS output: max load 2A) | |
Analog I/O (optional) | Max 4AI/2AO | |
| AI type (optional) | Thermocouple E/E_/K/K_/S/S_/T/T_/J/J_ / PT100/ PT1000/ NTC10K/ NTC50K/ NTC100K/ 0~10V/ 0~5V/ 0~20mA/ 4~20mA/ mixed | |
| AO type (optional) | 0~10V /0~5V/ 0~20mA/ 4~20mA/ mixed | |
| High-speed function | High-speed counting | Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz, or 2 ABZ 60KHz + 1 AB phase 10 KHz |
| High-speed pulse | 8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz. High-speed counting + high-speed pulse < 480KHz | |
| Connection | HMI | Type-C HMI download port (can download PLC program through the USB penetrating function), RS232 port |
| / | ||
| PLC | 1 TYPE-C, 1 RS232 (program port) | |
1 Rs485 or 2 Rs485 COM ports (one of which is changed from the default RS232 port); 1 WIFI (occupy default RS232 port) | ||
| Software | HMI | Coolmay mView HMI Programming Software |
| PLC | Compatible with Mitsubishi GX Developer 8.86 and WORKS 2 | |
Programmable logic controller that uses a type of programmable memory for its internal program to perform user-oriented instructions such as logic operations, sequence control, timing, counting, and arithmetic operations, and through digital or analog input/output Control various types of machinery or production processes.
|
|
