| Brand Name : | Coolmay |
| Model Number : | CX3G-32MR-2AD-A4-485/485 |
| Certification : | CE |
| Price : | usd64-usd115 per piece |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 5000pcs/month |
| Delivery Time : | 5-7 working days |
Industrial PLC Programmable Logic Unit 20mA Public Terminal Isolated
Industrial Control Plc Programmable 16 Digital Input 16 Digital Output
Coolmay PLC programmable controller adopts power separation technology for the first time in hardware innovation. It is ultra-thin, low heat, fast heat dissipation, stable and reliable, PLC is highly integrated with analog and temperature, powerful, easy to use, cost and space saving, and flexible. It has strong performance and can be used in various occasions requiring PLC control without external PLC expansion modules.
| Model | CX3G-32MR-2AD-A4-485/485 |
| Dimension | 130*90*36mm |
| Cutout size | 122*99mm |
| Installation | Fixed hole installation and DIN-Rail (35mm ) |
| Features | Support interrupt, linear arc interpolation, PID auto-tuning. 32K program capacity, 32K retentive register |
| I/O level | Input: Passive NPN, public terminal isolated Transistor output: NPN | Relay output: Normally open dry contact |
| Digital I/O | 16DI/16DO |
| DO type | Relay(MR) output: max load 5A |
| High speed counting | Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz, or 2 ABZ 60KHz + 1 AB phase 10 KHz |
| High speed pulse | 8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz |
| High-speed counting + high-speed pulse < 480KHz | |
| Analog I/O | 2AI |
| AI type | 4-20mA (Other type like E/E_/K/K_/S/S_/T/T_/J/J_ thermocouple / PT100/ PT1000/ NTC10K/ NTC50K/ NTC100K/ 0~10V/ 0~5V/ 0-20mA/ -5V~5V/ -10V~10V can also be made) |
| AO type | 0 |
| Default | 1 Mini type B USB programming port, 1 RS232 programming port (Interface terminal is mouse female port with 8 holes), 2 RS485 COM ports |
| Software | Compatible with WORKS 2 |
