Coolmay L02M24R Series Modules PLC Logic Controller Sermo Motor Controller

CPU Module: L02M24R

12 Input/12 Output Relay

4 Analog input: 2 voltage +2 current

4 Analog output: 2 voltage +2 current

Built-in Ethernet, RS-485*2, RS232, Type-C download
port, Micro SD card interface, CAN communication port

program Capacity 32k steps, using push-type terminals

Modbus plc

Features

Coolmay L02 series PLC is a high-function general-purpose controller specially designed for automation equipment. L02 series modules can be expanded up to 31 units.

Powerful positioning control function can support up to 8 axis high-speed pulse control at the same time.

Suitable for various automation equipment, such as electronics manufacturing, labeling, food packaging, textile equipment and other industry equipment.

Model		LO2M24R
Programming language		Ladder diagram(LD) / lnstruction list / Sequential function chart(SFC)
Program capacity		32k steps
Storage capacity	Date (D)	[D0~D127] 128points General / [D128~D7999] 7872points Retentive / [D8000~D8511]512points Special
	Expansion(R)	[R0~R22999] 23000points Support power-down retention / [R23000~R23999] 1000points Internal use
Expansion model		Max limit of 31 units: max 12 analog input/output respectively
Max l/O		FX3U mode: 512 points; FX3G mode: 256 points (the sum of input and output points)
CPU Digital I/O		12DI/ 12DO
CPU analog I/O		4AI/4AO
AI Type		2*0-10V, 2*0-20mA(4-20mA)
AO Type		2*0-10V, 2*0-20mA(4-20mA)
Timer T		[TO~T199] 200points 100ms General / [ [T250~T255] 6points 100ms Retentive [T246~T249] 4points 1ms cumulative Retentive / [T256~T319] 64points 1ms General [T200~T245] 46points 10ms General
		※The 10ms timer is affected by the scan period. lf the scan period is 12ms,the timer becomes 12ms and executes once.
16-bit counter C		[CO~C15] 16points General
32-bit counter C		[C220~C234] 15points Retentive
		[C235~C245 Single phase single counting][C246~C250 single phase double counting]
		[C251~C255 Two-phase double counting]
High-speed pulse		4-axis 200KHz+4-axis 50KHz (Y0-Y3 each 200KHz; Y4-Y7 each 50KHz, total should not be over 200KHz)
High-speed counter		Single phase 6 channels 60KHz, or AB(Z) phase 2 channels 60KHz+AB phase 1 channel 10KHz
Do type		LO2M32T/LO2M24T: Transistor output, load maximum 500mA, low level NPN, COM connected to negative
		LO2M32R/LO2M24R: Relay output, load maximum 2A, dry contact, COM can be connected to positive ornegative
Default COM		Type-C, RS-232, RS-485*2, Ethernet, CAN
Protocol		Programming port Modbus RTU, Modbus TCP, Modbus UDP, freeport protocol, CAN, Ethernet/IP, BD board
Data backup function No battery storage	Program	Flash ROM
	Retentive area	MRAM has no write limit
Calendar(RTC)		Commercially available batteries CR1620(optional)
Self-diagnosis		CPU abnormalities, internal memory problems, etc
Rated input voltage		24VDC(土10%)
Software		Compatible with GX WORKS 2
Detailed info. refer to Coolmay L02 Series PLC Progarmming Manual L02 Series PLC Controller User Manual
