HMI PLC All In One High Processing Speed 32bit CPU 408MHz RS485 COM
Ports
Each PLC has its own programming port (RS232). Two communication
ports (RS232 or RS485) are optional, and a CAN port is optional to
meet the needs of users to connect several types of equipment.
Advantage:
◆ Powerful, compatible with FX3G/FX3U/FX3S PLC, high processing
speed.
◆ Military level 32 bit CPU adopted, which is faster and more
adapted to industrial environment of high electromagnetic
interference.
◆ Clock supported, rechargeable battery adopted.
◆ Default with 1 HMI download port, 2 PLC programming ports
(RS232/MiniB USB port or Type-C), and one USB port.
◆ 32K program capacity, 32K retentive register, support interrupt,
linear arc interpolation ,PID auto-tuning, high powerful.
Parameter:
| Display | Dimension | 226*163*35.6mm |
| Cutout size | 217*154mm | |
| Type | 7"TFT | |
| Feature | 60K-color resistive touch screen, supports portrait display | |
| Memory | RAM | 64MB |
| ROM | NOR Flash 16MB | |
| CPU | 32bit CPU 408MHz | |
| I/O | DI/DO | Max 30DI/30DO (max 28MR) |
| DI/DO level | Input: Passive NPN, public terminal isolated | |
| DO type and load | Relay MR/MOS tube, MOS tube: 2A/point, 4A/4 point COM, 5A/12 point COM; MR: 2A/point, 5A/12 point COM. | |
Analog I/O | Max 12AI/8AO | |
| AI type (optional) | Thermocouple E/E_/K/K_/S/S_/T/T_/J/J_ / PT100/ PT1000/ NTC10K/
NTC50K/ NTC100K/ | |
| AO type (optional) | 0~10V /0~5V/ 0~20mA/ 4~20mA/ mixed/ | |
| High-speed function | High-speed counting | Single phase 6 channel 60KHz, or 2 AB 60KHz + 1 AB 10KHz, |
| High-speed pulse | 8 channels, Y0-Y3 is 100KHz, Y4-Y7 is 10KHz. | |
| Connection | HMI | Type-B HMI download port (can download PLC program through the USB penetrating function), RS232 |
| 1 RS485 (changed from default RS232) | ||
| PLC | 1 Mini USB, 1 RS232 (program port) | |
| 1 RS485 or 2 RS485 COM ports (one is changed from the default RS232 port) | ||
| CAN (2.0A/B) port, Ethernet port, WIFI (will occupy default RS232 port) | ||
| Software | HMI | Coolmay mView HMI Programming Software |
| PLC | Compatible with Mitsubishi GX Developer 8.86 and WORKS 2 |
Handwheel pulse function:
The handwheel pulse generator is commonly known as electronic
handwheel and handwheel. It is mainly used for the setting of the
teaching CNC machine work origin in CNC machine tools, manual
stepping fine adjustment, and interruption insertion during
processing. Widely used in CNC engraving and milling machines, CNC
milling machines, CNC lathes, machining centers, CNC wire cutting
machine tools, CNC EDM machine tools, printing equipment, textile
machinery and other fields.
|
|
