Modbus Hmi Touch Screen 65536 True Colors LED4-Wire Resistive Panel Ethernet Port
Human-Machine Interface (HMI) connects industrial control equipment such as programmable logic controllers (PLC), frequency converters, DC speed regulators, and meters. It is a digital device that uses the display screen to write working parameters or input operating commands through an input unit (such as a touchpad, a mouse, etc.) to realize information interaction between humans and machines. It consists of two parts: hardware and software.
PRODUCT DESCRIPTION
The main characteristics of the touch screen:
| Specs | Dimension | 88*88*25mm |
| Cutout size | 72*72mm | |
| Display size | 73*56mm | |
| Weight(kg) | Appox. 0.3 kg | |
| Display | Display | 3.5” TFT |
Resolution (pixels) | 320*240 | |
| Brightness | 300cd/m2 | |
| Contrast ratio | 400:1 | |
| Backlight | LED | |
| Backlight time | 60,000 h | |
| Display color | 65536 true colors | |
| Touch type | 4-wire resistive panel | |
| Storage | ROM | 128MB |
| RAM | 64MB | |
| CPU | ARM9 core 400MHz | |
| Operating system | WINCE 5.0 | |
| Interface | USB port | USB 2.0×1 (USB port and can be connected to external USB flash drive, mouse, etc.) |
| Download port | Yes (Mini type B male port cable for program download | |
| Ethernet port | Optional | |
| COM port | 1 RS232 and 1 RS485 | |
| Protocol | Support MODBUS, free port and common PLC communication Protocol | |
| Other | Audio | Optional |
| Calendar | Yes | |
| Input Voltage | Default as DC12~24±10%V | |
| Consumption | 100mA*24V | |
| Protection Class | IP65 (front panel) | |
| Temperature | Ambient environment: 0～50℃ | Storage environment: -20～70℃ | |
| Humidity | 20%～90% RH | |
| Certification | CE | |
| Software | CoolMay HMI programming software | |
The products will be under testing for 1-3 days and packed with carton box .
By courier, door to door
For samples, the package will be delivered by DHL/UPS/FedEx/EMS express. Usually it will take 3-7 days to your location.
Post service
If you are not hurry but need economical delivery, we can go with packet channel. The delivery time depends on your location.
Air shipping or by sea
If bulk order, the packages will be delivered by air shipping or by ship.
Service advantages
1. Production equipment
Coolmay, which has 15 years of expertise in automation solutions
for various industries, has6000 square meters of production space
and 10 production lines, many imported high-end smtplacement
equipment and testing equipment, and its monthly output can reach
50,000 units.
2. Certification
Coolmay has passed the ISO9001 quality management system
certification and the national high-tech enterprise certification.
lts products have obtained a number of utility model patent
certificatesand invention patents, and have repeatedly won many
awards such as "Technical lnnovationAward" and "Innovative Product
Award".
In addition, all Coolmay products have passed CE & RoHS
certification.
|
|
