    COOLMAY TK6050FH HMI Touch Screen Panel Scada Software 5inch TFT LCD Display

    Ask Lasest Price
    Brand Name : Coolmay
    Model Number : TK6050FH
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 15000 Units Per Week
    Delivery Time : 3-8 works days
    • Product Details
    • Company Profile

    COOLMAY TK6050FH HMI Touch Screen Panel Scada Software 5inch TFT LCD Display

    COOLMAY scada software 5inch TFT LCD display touch screen TK6050FH hmi


    PRODUCT DESCRIPTION

    Feature:


    • Resistive touch panel with high precision and reliability
    • 60,000 TFT true color display, all series support vertical display
    • Supports any-format static images and GIF animation
    • Supports all fonts in Windows
    • Provide a large number of vector libraries and component libraries
    • Button sound and alarm sound can be set by yourself
    • Multi-language, support to display multiple languages in the same screen, and have the function of translator

      1. Advantages

        1) Over 10 years brand, Specialized in PLC and HMI automation products studying since 2005.

        2) Powerful team, with experienced professional developing team, have already got many patent certificate

        3) Various products, and support customized service, you can always find your prefer one.

        4) Perfect after-service, support 18 months warranty under right operation, and support lifelong technical introduction.

        5) Free training , Case and software for plc controller and hmi touch panel etc will be kept updated in our official website.

        6) Exported directly, we are not only the developer, but also the manufacurer, you could get high quality products in very good price.

      ModelTK6050FH

      Resolution

      (pixels)

      800*480
      Brightness300cd/m²
      Contrast ratio400:1
      BacklightLED
      Backlight time60,000 hours
      Display color65536 colors
      Touch type4-wire resistive panel
      StorageROMNOR Flash 16MB
      RAM64MB (HMI when stores historical data, optional ferroelectric is required)
      CPU32bit CPU 408MHz
      InterfaceInterface

      - Download port: Type-C, RS232, RS485

      - COM port: RS232, RS485

      ProtocolRS232/RS485 supports MODBUS, free port and common PLC communication protocol
      CalendarYes
      Input Voltage12-24VDC±10%<150mA @ 24VDC
      Consumption85mA/24V
      Protection ClassIP65 (front panel)
      TemperatureAmbient environment: 0~50℃ | Storage environment: -20~70℃
      Humidity20%~90% RH
      CertificationCE
      Software

      CoolMay TPWorks HMI programming software

      Detailed info. refer to Coolmay TK Series HMI Programming Manual CoolMay TK HMI User Manual

      Programming software

      The coolmay-HMI programming software is completely free for users.

      Download link: http://www.coolmay.net/Download-159-36-41.html


      Coolmay Technology will quickly and accurately provide you with high quality industrial control products at competitive prices. Without a small order, the products will be tested from our workshops to ensure the highest quality.

      Company Information

      Shenzhen Coolmay Technology Co., Ltd,the developer and manufacturer of Coolmay brand serial products,including HMI,PLC and HMI/PLC ALL-IN-ONE and other industrial control products. Since its establishment in 2005,the company has been focusing in providing various products with high Quality and low price for industrial control,based on the belief of “Cooperation,Honesty,
      Down-to-earth,Innovation”.
